Cost-Effective Mini UV Laser Engraving Machine for Engraving Patterns on Various Materials Personal or Small Business

MOQ: 1 set
Price: USD799-999/Set
Standard Packaging: Wooden box
Delivery Period: 7-10 working days
Payment Method: T/T,Western Union
Supply Capacity: 10000 pcs one year
Details Information
Product Description
Detail Information
Place of Origin
Shandong, China
Brand Name
Xinhong Lasser
Certification
CE,RoHS,ISO9001 certificates
Model Number
XH-fiber laser marker
Product Name:
Fiber Laser Marking Machine
Laser Source:
Max/Raycus/JPT
Laser Type:
Ultraviolet Light
Power:
20W/30W/50W
Marking Area:
110/150/175mm(optional)
Galvanometer:
SINO-GALVO
Control System:
BJJCZ
Control Software:
EZCAD2.14.10
Machine Size:
54*43*29cm
Net Weight:
20KG
Product Description

Cost-Effective Mini UV Laser Engraving Machine for Engraving Patterns on Various Materials Personal or Small Business


★ Product Description
Small Mini laser marking machines 20w/30W/50W Portable Type Only 18KG

1. It is capable of processing various metal and non-metal materials, particularly offering greater advantages for marking high-hardness,

    high-melting-point, and brittle materials.

2. As a non-contact processing method, it causes no damage to the product, eliminates tool wear, and ensures high-quality marking.

3. The laser beam is extremely fine, resulting in minimal material consumption and a small heat-affected zone during processing.

4. With high processing efficiency and computer-controlled operation, it enables easy automation.

★ Product Application
laser marking machine can work with most metal marking applications, such as Gold, Silver, Stainless Steel, Brass, Aluminium,
Steel, Iron etc, and can also mark on many non-metal materials, such as ABS, Nylon, PES, PVC, Makrolon.

★ Product Features
√Small beam diameter and fine marking line
√Good quality and high laser beam stability
√Complete machine stability, simple and easy operation
√Narrow pulse width, small heat affected zone, workpiece without damage
√Suitable for sensitive material as cold light source

★ Technical Details

Device modelXH-Mini laser marking machine Portable Type
Output power20W/30W/50W
Laser source
Raycus/MAX
Marking range110*110mm(4.3in*4.3in)
150*150mm (5.9*5.9 in)
175*175mm(6.9in*6.9in) Optional
Marking Speed≤8000mm/s
Laser wavelength1064nm
Power supply220V 50hz
Lifespan100000 hours
Desktop Part Size 54*43*29cm
Desktop Weight20KG


★Product Details
Cost-Effective Mini UV Laser Engraving Machine for Engraving Patterns on Various Materials Personal or Small Business 0
Cost-Effective Mini UV Laser Engraving Machine for Engraving Patterns on Various Materials Personal or Small Business 1
1.Laser source has perfect laser characteristics and good pulse shape control ability. Compared with
Q-switched fiber lasers, the JPT series lasers have more flexibility, can achieve lower and higher frequencies,
and have a smaller opening delay.
2.High speed China galvanometer, with double red lights help you focus laser.
3.Choose field lenses of different formats according to your needs, the types are 70x70mm 110x110mm
150x150mm 175x175mm 200x200mm.

4.Genuine EZCAD control software and BJJCZ card which support XP / WIN7/ IN8/ WIN10, 32 / 64 bit
operating system.

★ Sample Show
Cost-Effective Mini UV Laser Engraving Machine for Engraving Patterns on Various Materials Personal or Small Business 2

About us
    Xinhong Machinery Manufacturing Co., Ltd is a professional high-tech enterprise integrating R&D,production and trade. Our company is mainly engaged in the developing, producing and exporting of fiber laser cutting machines, laser welding machines,laser marking machines,and metal processing machinery manufacturing. The mechanical equipment produced by the company is widely used in industrial fields and products are best-selling across the country and overseas markets.
    The company has a high-quality and professional management and technical team. "Quality First,Service First" is our manufacturing philosophy. To guarantee the interests of our customers, we promise lifelong after-sales service. With reliable quality and service, our products are deeply trusted by customers.
Cost-Effective Mini UV Laser Engraving Machine for Engraving Patterns on Various Materials Personal or Small Business 3
